    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification

    Ask Lasest Price
    Brand Name : GUOTE
    Certification : ISO:9001
    Supply Ability : 50 Set/Sets per Month
    Price : $10,000.00/sets >=1 sets
    • Product Details
    • Company Profile

    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification

    Superfine micron air classifier powder air classifier

    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification

    Product Description
    Overview:
    The classifying device is composed of pneumatic classifier, cyclone, collector, induced draft fan, control cabinet and so on. Equipped with second air inlet and vertical impeller rotor, the materials are fed in visa the bottom roller under the force generated from the induced draft fan and then mixed with first input air to disperse particle and then brought to classifying zone. Owing to the high rotary speed of classifying rotor, the particles are under the centrifugal force produced by the classifying rotor and centripetal force generated from induced draft fan. When the centrifugal force is stronger than the centripetal force, the coarse particles fall down along inside roller. The second air is induced to sieve the coarse material and separate the fine powder that stick on or mixed with the coarse. After the coarse material is discharged from classifier, the over-milled powder are collected by the cyclone and pulse collector.
    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification
    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification
    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification
    Product advantages:

    1.With special design for classifying structure and its high classifying precision, it can block big granular strictly.

    2.To get the required product, you can adjust the rotary speed of classifying wheel and air inlet volume.

    3.Single vertical rotor with low speed, steady flow field, high efficiency and robust performance.

    4.With multi-series structure, it can get products with different size to meet requirement


    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification

    Technical parameter:


    ModelCapacity(kg/h)Efficiencyof classification Product Particle Size(um)Power(kw)
    GF01010-5070-90%D97=3-507
    GF02050-35015-19
    GF050100-80025-30
    GF100300-150041-48
    GF200500-400063-73
    GF4002000-500097-20
    GF5003000-6000110-30
    GF6004000-8000140-169
    GF8006000-12000170-210
    GF12008000-2000070-90%D97=3-50230-280

    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification

    Company Information

    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification

    Certification

    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification

    International Trade Department

    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification

    Our customers :

    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification

    Our Services

    1.EPC service for single equipment and whole production line.

    2.OEM service for your personal equipment or production line

    3.Testing before delivery and Pretesting in working site until get qualified products

    4.24hours for technical Operation Guide and 4hours offer technical proposal for problem shooting.


    Packaging & Shipping

    Superfine Micron Air Classifier for Sustainable and Accurate Powder Classification


    FAQ

    Q: Why we believe in Weifang GuoteMining Equipment Company?
    A: 1. More than 10 years experience.


    Q. We are the leading professional supplier of mining equipments and service for quartz mining equipment industry.
    A. All products achieved ISO9001:2000 quality management certificate and EU CE certificate.


    Q: Delivery time
    A: The lead time is 10-30 days, delivery time will vary depending on the type of the machine, shipping method selected and part availability.


    Q: Payment terms
    A: Accepted Payment Type: T/T, L/C, Western Union, Cash.
    After sign the contract, pay the 30% deposit of total purchase price and pay the full payment before delivery.


    Q: What will you do if the machine is broken down?
    A: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.


    Q: What should I do if I want to get a best quotation?
    A: If you want a suitable type for you, please let us know your material and capacity.
