    Energy Mining GCT/F Series Dry Drum Magnetic Separator with Permanent Magnet

    Ask Lasest Price
    Brand Name : GUOTE
    Price : $5,889.00/sets
    Certification : ISO9001:2008
    • Product Details
    • Company Profile

    Energy Mining GCT/F Series Dry Drum Magnetic Separator with Permanent Magnet

    GCT/F series dry drum magnetic separator with permanent magnet


    Product Description

    Application


    1 It is used for ceramics, glass, refractories, abrasives and other non-metallic mineral

    2 It's apply to purification of chemical, food, medicine and purification, hematite,limonite and manganese.


    Technical characteristics


    • Cylinder and roller reasonablely combined, iron removal more efficient.
    • Cylinder with new type permanent magnet ,magnetic field more stronger, suction more stronger
    • Drum magnetic system can be turning block type, efficient more higher
    • Surface magnet field up to 8000GS
    • Cylinder and roller's speed is variable frequency regulation
    • Magnetic roller adopted polymer composite magnetic system,magnetic field up to 15000GS, higher gradient
    • Belt made with special materials, high wear resistance
    • Controllable feeding system ensure the uniformity of material when it go through magnetic field
    • Selfclean weakly magnetic oxide,longlife work
    • Dust discharged only by dust collector, so it can meet the environmental protection requirements

    Thenical parameter


    ITEM

    Magnetic roller length(mm)

    Magnetic field intensity(GS)

    cylinder magnetic field intensity(GS)

    Belt thickness(mm)

    Material size(µm)

    Capacity(t/h)

    Power(KW)

    MODEL

    Cylinder drive

    roller drive

    GCT/F3-I

    300

    1500-2000

    4000-10000

    0.1-2

    83-5000

    0.4-0.6

    0.75*2

    0.55*1

    GCT/F3-II

    0.55*2

    GCT/F5-I

    500

    1500-2000

    4000-10000

    0.1-2

    83-5000

    0.8-1

    0.75*2

    0.55*1

    GCT/F5-II

    0.55*2

    GCT/F8-I

    800

    1500-2000

    4000-10000

    0.1-2

    83-5000

    1.2-2

    1.1*2

    0.55*1

    GCT/F8-II

    0.55*2

    GCT/F10-I

    1000

    1500-2000

    4000-10000

    0.1-2

    83-5000

    2-3.5

    1.5*2

    0.55*1

    GCT/F10-II

    0.55*2

    GCT/F12-I

    1200

    1500-2000

    4000-10000

    0.1-2

    83-5000

    4-7

    2.2*2

    0.55*1

    GCT/F12-II

    0.55*2

    GCT/F15-I

    1500

    1500-2000

    4000-10000

    0.1-2

    83-5000

    7-10

    3*2

    0.55*1

    GCT/F15-II

    0.55*2
